The alumina ceramic fiber board is primarily composed of alumina, boasting high strength, excellent erosion resistance, ease of processing and cutting, light weight, and outstanding thermal insulation properties. It is widely utilized in high-temperature insulation applications and effectively withstands direct impact from high-temperature airflows and flames.
Brand:
ATCERAItem NO.:
AT-AO-XW1001Materials
Alumina CeramicShapes
PlateApplications
Metallurgy Industry
1. With low thermal conductivity, high temperature resistance, flame and airflow erosion resistance, the alumina ceramic fiber board can be directly used on hot surfaces and exhibits excellent thermal shock resistance.
2. The alumina ceramic fiber board features low density, light weight, ease of processing and cutting, as well as convenient installation.
1. Alumina ceramic fiber board can be used for furnace doors, linings, or backings in high-temperature kilns, flame barriers, and sealing materials.
2. As a thermal insulation and electrical insulation material for heating devices.
3. As a thermal insulation layer for molten metal ladles, such as steel ladles.
We are committed to delivering optimal alumina fiber boards tailored to your exact specifications. Our dedicated team ensures meticulous adherence to your instructions, striving to exceed customer expectations. Additionally, we offer the flexibility of custom sizes to accommodate your unique requirements.
Please provide parameters such as dimensions and operating temperature for customization.
| Alumina Ceramic Fiber Board | |||||
| Item no. | Length (mm) |
Width (mm) |
Thickness (mm) |
Operating Temperature (℃) |
SiO2+Al2O3 (%) |
| AT-AO-XW1001 | 600 | 400 | 20-150 | 1000℃-1800℃ | 96%-99.8% |
| AT-AO-XW1002 | 900 | 600 | 20—150 | 1000℃-1800℃ | 96%-99.8% |
| AT-AO-XW1003 | 1000 | 500 | 20-150 | 1000℃-1800℃ | 96%-99.8% |
| AT-AO-XW1004 | 1000 | 600 | 20-150 | 1000℃-1800℃ | 96%-99.8% |
| AT-AO-XW1005 | 1100 | 700 | 10-150 | 1000℃-1800℃ | 96%-99.8% |
| AT-AO-XW1006 | 1200 | 1000 | 10—150 | 1000℃-1800℃ | 96%-99.8% |
| Material | 99% Alumina (AL2O3) |
| Thermal Conductivity | 24.0w/m.k |
| Electrical Insulation | ≤22.5KV, temperature resistance up to 1600℃ |
| Density | 3.83g/cm3 |
| Thermal Expansion Coefficient | 7*10-6/℃ |
| Bending Strength (at room temperature) | 310MPa |
| Compressive Strength (at room temperature) | 2200MPa |
| Hardness (Hv) | 1650 |
| Fracture Toughness | 4.2MPa*m1/2 |
*This chart illustrates the standard characteristics of the alumina materials commonly employed in the manufacturing of our alumina products and parts. Please be aware that the attributes of customized aluminum oxide products and parts may vary depending on the specific processes involved.
Alumina fiber boards are carefully packaged in appropriate containers to avoid any potential damage.
1. According to your application scenario, analyze the needs, choose the appropriate material and processing plan.
2. Professional team, quick response, can provide solutions and quotations within 24 hours after confirming the demand.
3. Flexible business cooperation mechanism, support at least one piece of quantity customization.
4. Quickly provide samples and test reports to confirm that the product meets your needs.
5. Provide product use and maintenance suggestions to reduce your cost of use.
Although our primary focus is on advanced ceramic materials such as alumina, zirconia, silicon carbide, silicon nitride, aluminum nitride, and quartz ceramics, we are always exploring new materials and technologies. If you have a specific material requirement, please contact us, and we will do our best to fulfill your needs or find suitable partners.
Absolutely. Our technical team possesses profound knowledge of ceramic materials and extensive experience in product design. We are happy to provide you with material selection advice and product design support to ensure optimal performance for your products.
We do not have a fixed minimum order value requirement. We always focus on meeting our customers' needs, and we strive to provide quality service and products regardless of the order size.
In addition to ceramic products, we also provide a range of additional services, including but not limited to: customized ceramic processing services based on your needs, using blanks or semi-finished blanks produced by yourself; if you are interested in outsourced ceramic packaging and metallization services, please contact us for further discussion. We are always committed to providing you with a one-stop solution to meet your various needs.
Yes, we do. No matter where you are located globally, we can ensure the safe and timely delivery of your order.
