Quartz Ring For Etching Equipment

Quartz ring for etching equipment is a ring made of high purity quartz material, with high temperature and corrosion resistance, small thermal expansion coefficient and high optical transmittance. It is used in semiconductor manufacturing, installed between wafer and electrode, guide reaction gas to the surface of the wafer to be etched, and separate the finished product and the waste material, so as to ensure the quality and efficiency of etching.

  • Brand:

    ATCERA

  • Item NO.:

    AT-TAZ-ER001

  • Materials

    Quartz Glass

  • Shapes

    Mechanical Parts

  • Applications

    Semiconductor , Photovoltaic Cell Industry
Inquire Now
fused silica semiconductor etching ring

Properties of Quartz Semiconductor Etching Ring





Quartz ring for etching equipment has high temperature and corrosion resistance, small thermal expansion coefficient and high optical transmittance, and the service life is long.





















quartz silica semiconductor etching ring

Applications of Quartz Semiconductor Etching Ring











Quartz ring for etching equipment is used in semiconductor manufacturing, installed between wafer and electrode, guide reaction gas to the surface of the wafer to be etched, and separate the finished product and the waste material, so as to ensure the quality and efficiency of etching.

















Customization Design of Quartz Semiconductor Etching Ring

We are committed to delivering optimal quartz semiconductor etching rings tailored to your exact specifications. Our dedicated team ensures meticulous adherence to your instructions, striving to exceed customer expectations. Additionally, we offer the flexibility of customized sizes to accommodate your unique requirements.



Drawing and parameter requirements shall be provided if customized design request.



Send Requirements for Custom Design





Quartz Semiconductor Etching Ring
Item no. Dimension
(inch)		 Outer Dia.
(mm)		 Thickness
(mm)		 Purity
(%)
AT-TAZ-ER001 2 50.8 3 99.99
AT-TAZ-ER002 4 101.6 4 99.99







Technical Data of Fused Quartz Materials

Density (g/cm3) 2.2
Flexture Strength (MPa) 48
Elastic Modulus (GPa) 72
Poisson's Ratio 0.14-0.17
Compressive strength (MPa) 1100
Bending strength (MPa) 67
Moh's hardness 5.5~6.5
Maximum working temperature (long-term, ℃) 1100
Maximum working temperature (short-term, ℃) 1350
Thermal conductivity (W/m*K) 1.4
Thermal expansion coefficient (/℃) 5.5*10-7
Specific resistance (Ω*cm) 7*107



*This chart illustrates the standard characteristics of the quartz materials commonly employed in the manufacturing of our quartz products and parts. Please be aware that the attributes of customized quartz products and parts may vary depending on the specific processes involved.






Quartz Ring For Etching Equipment

Valuable Information



Quartz Semiconductor Etching Ring Packing

Quartz Semiconductor Etching Ring Packing







Quartz semiconductor etching rings are carefully packaged in appropriate containers to avoid any potential damage.















Customization Advantages
Customization Advantages





1. According to your application scenario, analyze the needs, choose the appropriate material and processing plan.



2. Professional team, quick response, can provide solutions and quotations within 24 hours after confirming the demand.



3. Flexible business cooperation mechanism, support at least one piece of quantity customization.



4. Quickly provide samples and test reports to confirm that the product meets your needs.



5. Provide product use and maintenance suggestions to reduce your cost of use.
