Magnesia Ceramic Tube Magnesium Oxide Pipe

Magnesium oxide ceramic tube is resistant to high temperature and corrosion, also with good electrical insulation, can be used as electric heater protection tube, thermocouple protection tube, cable insulation tube, etc.



  • Brand:

    ATCERA

  • Item NO.:

    AT-MO-G1001

  • Materials

    Magnesia (MgO) Ceramic

  • Shapes

    Tube

  • Applications

    Electronics and Electricity , Metallurgy Industry
Inquire Now
MgO Tube

Advantages of Magnesium Oxide Tube





Magnesium oxide ceramic tube is resistant to high temperature and corrosion, can resist over 2000℃ temperature, and can contact directly to various chemical substance, also with good electrical insulation.



application of Magnesia ceramic pipe

Applications of Magnesia Ceramic Tube





Magnesium oxide ceramic tube can be used as electric heater protection tube, thermocouple protection tube, cable insulation tube, etc.











Size Chart of Magnesia Ceramic Tube



Committed to providing optimal magnesia ceramic tube customized to your precise needs. Our devoted team guarantees careful adherence to your instructions, aiming to surpass customer expectations. Moreover, we provide the flexibility of customized sizes to meet your unique requirements.



Send Requirements for Custom Design



Please provide drawing and parameter requirements for customization.

Magnesia Ceramic Tube Single-bore
Item NO. Outer Diameter
(mm)		 Inner Diameter
(mm)		 Length
(mm)		 Purity
(%)
AT-MO-G1001 1.2  0.5  30 99.5
AT-MO-G1002 3.7  2.0  30 99.5
AT-MO-G1003 3.9  1.3  30 99.5
AT-MO-G1004 5.0  2.0  30 99.5
AT-MO-G1005 5.0  3.0  30 99.5
AT-MO-G1006 5.5  2.0  30 99.5
AT-MO-G1007 6.4  3.4  40 99.5
AT-MO-G1008 7.0  4.0  40 99.5
AT-MO-G1009 8.0  5.0  40 99.5
AT-MO-G1010 9.0  6.0  40 99.5
AT-MO-G1011 13.0  9.0  50 99.5
AT-MO-G1012 14.0  8.0  50 99.5
AT-MO-G1013 15.0  10.0  50 99.5
AT-MO-G1014 16.0  9.0  50 99.5
AT-MO-G1015 18.0  10.0  50 99.5
AT-MO-G1016 19.0  19.0  50 99.5
AT-MO-G1017 1.2-25 0.5-20 30-500 99.5





Magnesia Ceramic Tube Double-bores
Item NO. Outer Diameter
(mm)		 Inner Diameter
(mm)		 Length
(mm)		 Purity
(%)
AT-MO-G2001 5.3  1.6  25 99.5
AT-MO-G2002 7.0  2.4  40 99.5
AT-MO-G2003 9.0  3.0  50 99.5
AT-MO-G2004 11.0  3.5  40 99.5
AT-MO-G2005 15.0  4.5  40 99.5
AT-MO-G2006 18.0  5.0  50 99.5
AT-MO-G2007 13.0  4.5  40 99.5
AT-MO-G2008 20.0  6.0  50 99.5





Magnesia Ceramic Tube Three-bores
Item NO. Outer Diameter
(mm)		 Inner Diameter
(mm)		 Length
(mm)		 Purity
(%)
AT-MO-G3001 6.6 1.3 50 99.5
AT-MO-G3002 6.6 1.3 100 99.5
AT-MO-G3003 9 3 50 99.5
AT-MO-G3004 13.6 2.3 50 99.5
AT-MO-G3005 18 5 100 99.5
AT-MO-G3006 20 6 100 99.5





Magnesia Ceramic Tube Four-bores
Item NO. Outer Diameter
(mm)		 Inner Diameter
(mm)		 Length
(mm)		 Purity
(%)
AT-MO-G4001 4.0  1.1  20 99.5
AT-MO-G4002 5.0  1.3  25 99.5
AT-MO-G4003 6.0  1.4  25 99.5
AT-MO-G4004 7.0  1.6  25 99.5
AT-MO-G4005 8.0  1.8  25 99.5
AT-MO-G4006 9.0  2.5  25 99.5
AT-MO-G4007 11.0  3.0  40 99.5
AT-MO-G4008 12.0  3.5  40 99.5
AT-MO-G4009 13.0  4.0  40 99.5
AT-MO-G4010 15.0  4.0  50 99.5
AT-MO-G4011 16.0  4.0  40 99.5
AT-MO-G4012 17.0  5.0  50 99.5
AT-MO-G4013 18.0  5.0  50 99.5
AT-MO-G4014 19.0  5.5  50 99.5
AT-MO-G4015 20.0  5.5  50 99.5
AT-MO-G4016 22.0  6.0  50 99.5
AT-MO-G4017 24.0  6.8  50 99.5
AT-MO-G4018 25.0  7.0  50 99.5
AT-MO-G4019 26.0  7.0  50 99.5
AT-MO-G4020 28.0  8.0  50 99.5





Magnesia Ceramic Tube Seven-bores
Item NO. Outer Diameter
(mm)		 Inner Diameter
(mm)		 Length
(mm)		 Purity
(%)
AT-MO-G7001 9 1.8 25 99.5
AT-MO-G7002 11 2.5 25 99.5
AT-MO-G7003 13 3 30 99.5
AT-MO-G7004 15 3.5 35 99.5
AT-MO-G7005 17 4 40 99.5
AT-MO-G7006 18 4.5 40 99.5
AT-MO-G7007 20 4.5 50 99.5
AT-MO-G7008 22 5 50 99.5
AT-MO-G7009 25 5 50 99.5
AT-MO-G7010 27 7 50 99.5
AT-MO-G7011 29 7 50 99.5
AT-MO-G7012 33 7 50 99.5
AT-MO-G7013 48 8.3 50 99.5











Technical Data of Magnesium Oxide Materials

Purity (%) >99%
Density (g/cm3) 3.52-3.56
Bending Strength (MPa) 18
Compressive Strength (MPa) 50
Hardness (Moh's) 6
Maximum Working Temperature (℃) 2200
Thermal Conductivity (W/m*K) 5
Thermal Expansion Coefficient (/℃) 13*10-6
Volume Resistivity (Ohm*cm) 1*1013
Dielectric Strength (kV/mm) 5.8



*This chart illustrates the standard characteristics of the magnesium oxide materials commonly employed in the manufacturing of our magnesium oxide products and parts. Please be aware that the attributes of customized magnesium oxide products and parts may vary depending on the specific processes involved.






Magnesia Ceramic Tube Magnesium Oxide Pipe

Valuable Information



MgO ceramic tube

Magnesia Ceramic Tubes Packing





High purity magnesia ceramic tubes are carefully packaged in appropriate containers to avoid any potential damage.







Customization Advantages
Customization Advantages





1. According to your application scenario, analyze the needs, choose the appropriate material and processing plan.



2. Professional team, quick response, can provide solutions and quotations within 24 hours after confirming the demand.



3. Flexible business cooperation mechanism, support at least one piece of quantity customization.



4. Quickly provide samples and test reports to confirm that the product meets your needs.



5. Provide product use and maintenance suggestions to reduce your cost of use.
